Portable Moisture Meter

The Portable Moisture Meter delivers a reliable, precise, and easy-to-use solution for measuring moisture in wood, flooring, bamboo, laminates, and other building materials. Featuring Lignomat’s advanced technology and a bright, virtually unbreakable LED display, the meter ensures accurate readings even in poorly lit areas. Its ergonomic, compact design allows professionals to perform quick measurements on-site, from thin veneers to large logs, making it perfect for woodworkers, floor installers, inspectors, and restoration specialists. With multiple species correction settings, external probe support, and a wide measurement range, this meter combines versatility, durability, and accuracy in a convenient, portable package.

Measurement Capabilities

The mini-Ligno DX/C provides 42 correction settings for:

• Domestic and tropical wood species
• Horizontal, vertical, and strand bamboo
• Laminates and panel products
• Gypsum and drywall
• A reference scale for concrete and other building materials

You can choose from several electrode options depending on your needs. Pins can measure up to 7″ deep, making the device suitable for materials ranging from thin veneers to large logs. Unlike pinless meters, pin meters work on nearly any shape as long as both pins touch the same piece.

Technical Specifications

• Measuring Range: 5–65% (varies by species setting)
• Display: Bright LED with 0.1% resolution below 10% and 1% steps above 10%
• Species Corrections: 42 settings, including bamboo and panel products
• Gypsum Scale: 0–7.5%
• Reference Scale: 0–99 for non-wood materials
• Calibration: Stable and internally monitored for automatic adjustment
• Calibration Check: Optional external calibration block available
• Included Items: Pins (3/16″ and 7/16″), wrist strap, pouch, 9V battery, manual, and laminated chart
• Connector: DX model uses built-in pins; DX/C supports external probes
• Size: 70 × 140 × 25 mm
• Weight: 200 g (high-impact plastic)
• Warranty: 2-year meter warranty, lifetime LED display warranty

Key Features

• Ergonomic shape that fits comfortably in your hand
• Wide measuring range (5–65%) for both dry flooring and wet lumber
• Bright LED display visible in dark areas
• 40+ wood species correction settings
• Reference scale for drywall, plaster, and other soft building materials
• External probe support for testing concrete or insulated areas

Design and Ease of Use

The Portable Moisture Meter is compact enough to fit in your shirt pocket. The green cap covers the pins during transport and doubles as a handle for inserting the pins into wood. You can store longer pins inside the meter, making it convenient to switch between surface and deep measurements.

To take a reading, simply push the pins into the wood. The switch between the pins turns the meter on automatically, and the LED lights immediately show the moisture level. This simple operation ensures quick, accurate, and consistent results.

Why Choose This Moisture Meter?

The Portable Moisture Meter stands out for its precision, versatility, and durability. With 42 species correction settings, it accommodates domestic and tropical woods, bamboo, laminates, panels, and even gypsum and drywall. Its bright LED display ensures clear readings in low-light conditions, while the ergonomic design fits comfortably in your hand for extended use. External probes allow measurement in concrete, insulated, or hard-to-reach areas, expanding its usability beyond typical wood applications. The meter’s built-in calibration system maintains accuracy over time, and optional calibration blocks provide additional verification. Compact, lightweight, and easy to operate with automatic power-on, it delivers quick, reliable results for professionals who require consistency and accuracy in moisture measurement across a wide range of materials.
