Sharp Point Tester
Precision Sharp Point Tester for detecting hazardous points in toys. Compact, lightweight, and compliant with ISO, EN-71, ASTM, and international safety standards.
- Detects hazardous sharp points to meet global toy safety standards.
- Lightweight, accurate, and easy to operate for QC and lab use.
- Ideal for toy manufacturers, inspectors, and testing labs.
Application
The Sharp Point Tester determines whether points on toys and other articles intended for children under 8 years pose a risk of puncture or laceration. It evaluates points exposed during normal use or those revealed through reasonably foreseeable damage or abuse, ensuring they do not create potential safety hazards.
Standards
- ISO 8124-1 section 5.9
- EN-71-1 section 8.12
- 16 CFR 1500 section 48
- ASTM F 963 section 4.9
- GB6675-2 section 5.9
- EN 16890-2017 Section 8.4
Dimensions
- External Dimensions: 112*16*16mm (L*W*H)
- Package Dimensions: 200*150*120mm (L*W*H)
- Gross Weight: 1.5kg
- Net Weight: 1kg
Test Principle
The device has a slot with 0.04 inches width and 0.045 inches long rectangular opening, the two reference sizes sharpness are inserted into the depth of 0.015 inches deep hole of the sensor head. And overcome the spring of 0.5-pound elastic to cause the sensor head to move 0.005 inches again. That was identified as sharp point.
Key Specifications
- Bottom slot: 0.040 x 0.045 inch (1.15 x 1.02mm)
- Touched depth (Slotted vane thickness): 0.015 inch (0.38mm)
- Spring elastic force: 0.5LB@0.005inch
- Power: 12V 23A Battery
- Weight: 450g
Application Industry
All kinds of materials can be tested on the Sharp Point Tester
Why Choose This Sharp Point Tester?
Choosing this Sharp Point Tester ensures accurate, repeatable, and globally compliant safety evaluations for toys and children’s products. Its precision-engineered slot and spring system strictly follow international testing requirements, making it suitable for manufacturers exporting to Europe, the USA, and Asia. The device’s sensitive 0.5 lb elastic force mechanism provides highly reliable detection of hazardous points, minimizing safety risks and product recalls. Its lightweight design, durable construction, and battery-powered operation allow for convenient use in laboratories, production lines, or on-site inspections. Whether testing plastic, metal, rubber, or composite materials, this tester delivers consistent performance, ensuring your products meet mandatory safety standards and boost consumer confidence.
